Specs

Jeep YJ HumpHugger

Part Number:

• • JWYJHH-8795

What’s Included:

• • Padded Armrest
  • Two Large Drink Holders
  • Expansive Storage Compartment, 700 Cubic Inches (under armrest)
  • USB Dual Charging Port
  • Hidden Storage area concealed beneath the drink holders
  • CB radio compartment

Dimensions:

• • 8.25″ Width at Main Body
  • 11.00″ Width, at Drink Holders
  • 18.75″ Length
  • 19.00″ Height, at Tallest Point (rear of console)
  • 13.00″ Height, at Lowest Point (front of console)
  • CB Radio Compartment: 5.00″W  x  2.125″H  x  8.50″ D

Vehicle Guide

Jeep Wrangler YJ HumpHugger Console

Part Number: JWYJHH-8794

• • Jeep Wrangler (YJ) 1987 – 1995
  • Jeep Wrangler (CJ) – This console will work on Jeep Wrangler CJ models ONLY if the factory seats have been replaced with YJ seats.

Installation

Jeep YJ HumpHugger Console

Installation is fast and easy!

No tools needed, no permanent changes to your interior*. This consoles slides down between the OE bucket seats and rests on the transmission tunnel.

USB Port – The USB port comes with 20″ fused, wire pigtails for ease of installation. We encourage you to seek a professional, qualified mechanic who is familiar with vehicle electrical systems and wiring methods to connect the USB to a proper power source.

CB Compartment – The CB radio compartment is just that, a compartment. The purchase of this console does not include a CB radio, rather it allows you the option to install your own CB radio. The CB radio compartment is located on the front face of the console, below the USB port. The compartment is 5.00″ wide x 2.125″ high x 8.50″ deep.

* In order for the USB port to work safely and properly, it will involve wiring to a DC electrical source within the vehicle.

Vinyl Color Options

Color Options from Classic Consoles

With our large selection of in-stock automotive grade vinyl, you are sure to find the right color and grain to match your vehicle. We can even use your own material to cover any console design, no extra cost to you. In most cases, we’ll only need one yard of material to fully cover most console designs. Optional two-tone colors are available for most console designs whether you are choosing from our vinyl selection or providing your own material.

In addition to the standard color options, we offer a host of premium vinyl colors which are available for an additional cost of $16.00 per console. These colors are limited and unique to certain vehicle models and years. The additional cost is due to their random availability and the premium cost to obtain from suppliers. If these vinyl options are listed on the product page  colors then they are currently available for your console.

Vinyl Samples are available to make it easier to pick the right color or grain. We’ll ship the sample at no cost, directly to you.

Email us at Contact@ClassicConsoles.com to request sample vinyl swatches, ordering two-tone color options or using your own upholstery material.

Drink Holder Options

The drink holders in our consoles are made from durable, long-lasting polymers that will provide many, many years of functionality while retaining the striking appearance you expect from Classic Consoles. All drink holders come standard with a black finish around the top rim.  The top rim is the area of the drink holder predominately seen when the console is installed in your vehicle so we offer you the option of four additional distinct colors & finishes to customize your console or match the existing trim package of your vehicle’s interior.

Our large-sized drink holders are included with this console, they accommodate virtually all types of soda & energy drink cans, most plastic water bottles and larger coffee cups.  The bottom half of our large drink holders have a unique step down shape to allow smaller drink containers a secure hold while the upper half is large enough to hold bigger beverages with larger diameters.

You also have an option to upgrade the Large Drink Holders in this console to our brand new Mega Drink Holder. The Mega Drink holder is specifically designed to hold large, insulated beverage containers by maintaining a wide diameter from top to bottom and does not “step down” like the Large Drink Holder. We built the Mega Drink Holder as a special request from many of our great customers who wanted a better fitting drink holder for their large insulated mugs, like many of the Yeti styles.

Large Drink Holder Dimensions

• 3 5/8 inch upper interior diameter (3.691″ to be exact)
• 2 13/16 inch lower interior diameter
• 3 1/4″ inch interior depth

Mega Drink Holder Dimensions

• 3 5/8 inch interior diameter, from top to bottom (3.667″ to be exact)
• 3 3/8 inch interior depth
• Removable insert included so smaller drink sizes may stay secure

Rim Color Options:

• Black
• Chrome
• Pewter
• Matte Silver
• Camouflage

Rim Color Options, Right to Left, Top Row – Chrome, Matte Silver Bottom Row: Pewter, Camo & Black
